Simply Capable
The Quick Haul is a built-to-last compact e-bike that’s ready to tackle your daily grind. Think of it as the multitool of e-bikes: small and unassuming enough to be your daily go-to, yet capable of handling big jobs with finesse.
Designed to Be Used—Often
The Quick Haul makes doing stuff by bike practical, easy, and fun—so you’ll reach for it just about every day. It’s designed to help you carry passengers and cargo with ease, and it’s a joy to ride. A compact, space-saving design simplifies storage and transport.
The Carrying Capacity You Need
The short, low-capacity rear racks found on most city bikes limit how much you can do by bike (and make defaulting to a car more likely). The Quick Haul features an extra-long rear rack with a 50-kg (110 lb) capacity, so you can do a lot more—from hauling groceries to giving your kid a lift to school. Add an optional front rack to do both at once.
What Makes it a D8?
Bosch Active Line Plus motor provides up to 50 Nm of torque and 270% support
1x8-speed Shimano Altus groupset with trigger shifter
Quick Haul Highlights
Cargo capacity: 50 kg on the rear rack, plus an additional 20 kg with optional front rack
Fits riders 150 - 195 cm (4’11” - 6’5”) tall, with adjustable seatpost and Speedlifter stem (no tools required)
Lots of available kid- and cargo-carrying accessories—easily create your perfect setup
Ultra-low 490 mm standover height makes (dis)mounting and waiting at stops easier
Shimano hydraulic disc brakes for reliable stopping power—even when heavily loaded and riding fast
Proven safe and reliable: frame and fork are EFBE-tested up to the 150 kg (331 lb) Maximum Gross Vehicle Weight
If you were buying a car, you’d assume your spouse, partner, teenager, and best friend could use it, too. The same should go for your e-bike, which is why we outfitted the Quick Haul with an adjustable stem and seatpost to fit riders 150 - 195 cm (4’11” - 6’5”).
Key Features & Benefits
- Tern 6061 series aluminium frame:makes the Quick Haul an extremely versatile and adaptable bike.
- Bosch Active Line Plus Motor:Provides the all important assistance when the HSD is fully laden.
- Shimano hydraulic disc brakes:Provide all of the stopping power you will need if laden.
Full Specification
- Frame:Tern Quick Haul, Patented Design, 6061-AL, EFBE Tri-Test approved: 150 kg
- Fork:Cargo, steel, EFBE approved: 150 kg
- Motor:Bosch Active Line Plus, 270% Assist, 50 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
- Battery:Bosch PowerPack 400
- Controller:Bosch Purion, 4 mode selectable, walk assist
- Number of Gears:8
- Gear Shifters:Shimano Altus, 1 x 8 spd, trigger
- Chainset:Terncustom, forged 6061-AL crankarm
- Chainrings:Not Available
- Rear Cassette:Shimano 11-34T, 8 spd
- Chain:KMC for eBike, 8 spd
- Front Derailleur:N/A
- Rear Derailleur:Shimano Altus Shadow
- Bottom Bracket:Motor integrated
- Pedals:Urban with non-slip surface, sealed bearings
- Rims:Kinetix Comp, for disc
- Front Hub:Shimano disc
- Rear Hub:Shimano disc
- Front Tyre:Schwalbe Big Apple, 55-406, puncture protection, Reflex
- Rear Tyre:Schwalbe Big Apple, 55-406, puncture protection, Reflex
- Brakes:Shimano, hydraulic disc
- Handlebars:Low riser, 31.8, 6061-AL
- Handlebar Tape:Velo ergonomic, lock-on
- Headset:Tern Flux, cartridge bearings, Physis integrated
- Stem:Speedlifter, 150 mm extension, 3D Forged stem, 31.8
- Saddle:Velo Comfort
- Seatpost:31.6 mm, 6061-AL, micro-adjust clamp
- Accessories:Bosch 2A Charger
- Bell:Aluminium
- Chaingauard:SKS CHainbalde
- Kickstand:Pletscher design, rear mount
- Luggage Socket:Combo Mount
- Front Light:Herrmans, 120 lumens
- Rear Light:Herrmans
- Mudguards:Chromeplastic, stainless hardware
- Rack:Atlas Q Rack, UpperDeck Mount System, Vertical Parking, 50 kg capacity
- Weight:25.7 kg (56.5 lb)
