Cube Stereo Hybrid One77 HPC Race delivers 170mm travel, Bosch CX motor, Shimano 12-speed gears, hydraulic disc brakes, and advanced carbon frame for big mountain adventures.
Cube Stereo Hybrid One77 HPC Race delivers 170mm travel, Bosch CX motor, Shimano 12-speed gears, hydraulic disc brakes, and advanced carbon frame for big mountain adventures.
Cube

Cube Stereo Hybrid One77 HPC Race Electric Mountain Bike 2025 in Liquid Orange Orange

£3,799.00 £3,999.00 5% off
Size Guide
Earn
in Customer Rewards when you buy this item today
Sign Up
Sign In
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

Hassle free returns

In the unlikely event that you are not satisfied with your purchase please feel free to return your items within 90 days of the purchase date for a full exchange or refund. Any item (excluding food, underwear or e-gift vouchers) can be returned to us for any reason within 90 days, provided that the item has not been used or fitted and is returned in its original packaging with valid proof of purchase.

It is recommended that you use a recorded delivery service or return to a store to ensure your items are received by us. We cannot assume responsibility for items that are lost in transit back to us.

Returning an item

Online or in-store purchases can be returned to any of our 12 stores free of charge or can be returned by post or courier at your cost after completing the online returns form below. If you are returning an item due to a fault, we will refund your postage costs.

Bikes & Bulky items

If you wish to return a bike or bulky item to us, please keep the box it arrived in and let us know by contacting our support team via our online webchat, email or by phone (020 45063856) and we will help arrange a collection.

Non Bike - Customer Returns Form

If you wish to return or exchange an item, please fill out the form below following the steps inside. Returns can be processed quicker if all required information is provided.




Terms & Conditions

Items must be returned in their original packaging and unused. Refunds will be issued once the product(s) have been received and inspected.

Click & Collect customers can buy with confidence knowing that they can review the item before deciding whether it is right for you before leaving the store. Should you decide it's not right for you, it can be conveniently exchanged or refunded straight away, or you still have up to 90 days to return it if you are still unsure.

Please note:
1. If the items we have sent you are faulty, damaged or not as we described, we will cover the cost of collection and the delivery of the correct item.

2. If we have delivered the correct bike but upon inspection, you decide the bike is not the one for you, we will charge you £50 for collection (£100 from Northern Ireland). If you do not have the original box in usable condition, we will charge you an additional £15 to provide one.

Refunds will be processed using the same method of payment used for the original purchase. Credit & debit card refunds must be made to the card used for the original purchase.

We are unable to offer a refund without a valid proof of purchase.

Cube Stereo Hybrid One77 HPC Race Electric Mountain Bike 2025 in Liquid Orange Orange

Season:2025Sale

Brand:Cube

Code:803110ORGORG

The Stereo Hybrid ONE77 HPC frame – with 170mm travel front and rear and a mullet wheel setup with 29in front and 27.5in rear – is all you need for big days out on big mountain trails.

But, as with all CUBE designs, the devil is in the detail. So, for example, they added Integrated Cable Routing for super-clean looks and reduced maintenance, and then threw in an angle-adjustable headset so that you can tweak the handling to your taste. The PowerTube battery sits unobtrusively in the carbon down tube, just above the Bosch CX drive. A UDH dropout on the aluminium rear triangle is tough and future-proof, and they also added a direct mount chainguard to keep you driving forwards even when the going gets rough.

Key Features & Benefits:

  • 250W Bosch Motor:Most reliable pedal-assist motor in e-bike industry, capable of sustaining speeds up to 25 km/h
  • Hydraulic Disc Brakes:Reliable braking performance to keep you in control, whatever the weather.
  • 12 Shimano Gears:Wide range of gears suitable for a range of terrain, with the simplicity of a single shifter.

Full Specification:

  • Frame:C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
  • Rear Shock:SR Suntour Edge EVO 2CR 230x65mm
  • Fork:SR Suntour Aion 38X 2CR Air, Tapered, 15x110mm, Lockout, 170mm
  • Motor:Bosch Drive Unit Performance Line CX BDU38 (85Nm) Cruise (250Watt), Smart System
  • Battery:Bosch PowerTube 800
  • Controller:Bosch system control with mini remote
  • Charger:Bosch 2A
  • Number of Gears:12
  • Gear Shifters:Shimano Deore SL-M6100, Rapidfire-Plus
  • Chainset:ACID MTB Hybrid Pro, 36T
  • Chainrings:34T
  • Rear Cassette:Shimano Deore CS-M6100, 10-51T
  • Chain:KMC e12
  • Front Derailleur:N/A
  • Rear Derailleur:Shimano Deore RD-M6100-SGS, ShadowPlus, 12-Speed
  • Pedals:ACID PP MTB
  • Rims:CUBE EX30, 32H, Disc, Tubeless Ready
  • Front Hub:CUBE Engineered By Newmen, 15mm, Boost, 6bolt
  • Rear Hub:CUBE Engineered By Newmen, 12mm, Boost, 6bolt
  • Front Tyre:Schwalbe Magic Mary, Performance, 2.4
  • Rear Tyre:Schwalbe Big Betty, Performance, 2.4
  • Brakes:Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
  • Handlebars:CUBE Rise Trail Bar 35
  • Grips or Bar Tape:ACID Disrupt, Soft Compound
  • Headset:ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment
  • Stem:CUBE Performance Stem E-MTB 35, FPI-Link
  • Saddle:ACID Venec lite
  • Seatpost:CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
  • Accessories:Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
  • Weight:25.2 Kg Approx

Manufacturers reserve the right to change specifications without notice based on availability at the point of assembly.

Cube Stereo ONE77 Geometry Guide

Slack/ModerateMLXLXXL
Seat tube405420470470
Top Tube Horizontal589 / 591610 / 611633 / 635659 / 661
Seat angle76.7° / 76.5°76.7° / 76.5°76.7° / 76.5°76.7° / 76.5°
Head tube angle63.8° / 64.4°63.8° / 64.4°63.8° / 64.4°63.8° / 64.4°
Chainstays435435435435
Head tube103105115135
Wheelbase1229 / 12221250 / 12421274 / 12671297 / 1289
BB-Height to Hub-27 / -25-27 / -25-27 / -25-27 / -25
Protrusion height - 80mm743 / 747740 / 744766 / 770767 / 771
Reach452 / 450472 / 470492 / 490512 / 510
Stack626 / 627627 / 629636 / 638654 / 656

MLXLXXL
Length seat post418.3475.1475.1475.1
Diameter seatpost31.631.631.631.6
Crank length170170170170
Diameter tire maximum760760760760
Width tire maximum65656565
Stem length40405050
Handlebar width780800800800
Stroke seatpost150175175175
Rear suspension travel170170170170

Warranty Information for Cube:

Your CUBE bike is warranted to be free from manufacturing defects for 2 years with effect from the date of sale. In addition, we provide our customers with the following warranty in the event of frame breakage outside the statutory warranty period as follows:
For all frames and rigid forks from model year 2012 and onwards Cube guarantee from the date of sale from the dealer:
Aluminium: 6-year guarantee
Carbon fibre, aluminium-carbon fibre: 3-year guarantee
If a break occurs during this period (from date of sale), Cube will replace the item with the same or similar.
BOSCH Warranty (E-Bikes): The warranty period is 24 months.
For full warranty policy please visit cube.eu

Technical Information
  • Frame
    C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
  • Size
    S, M, L, XL
  • Suspension Fork
    SR Suntour Aion 38X 2CR Air, Tapered, 15x110mm, Lockout, 170mm
  • Shock
    SR Suntour Edge EVO 2CR 230x65mm
  • Shock Hardware
    Front: 30x8mm, Rear: DU-Bushing 12,7mm
  • Drive Unit
    Bosch Drive Unit Performance Line CX, Smart System
  • Remote
    Bosch System Control incl. Mini Remote
  • Battery
    Bosch PowerTube
  • Charger
    Bosch 2A
  • Brake System
    Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
  • Rear Derailleur
    Shimano Deore RD-M6100-SGS, ShadowPlus, 12-Speed
  • Shifters
    Shimano Deore SL-M6100, Rapidfire-Plus
  • Crankset
    ACID MTB Hybrid Pro, 36T
  • Cassette
    Shimano Deore CS-M6100, 10-51T
  • Chain
    KMC e12
  • Chain Guide
    Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
  • Headset
    ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment
  • Stem
    CUBE Performance Stem E-MTB 35, FPI-Link
  • Handlebar
    CUBE Rise Trail Bar 35
  • Grips
    ACID Disrupt, Soft Compound
  • Rims
    CUBE EX30, 32H, Disc, Tubeless Ready
  • Front Hub
    CUBE Engineered By Newmen, 15mm, Boost, 6-Bolt
  • Rear Hub
    CUBE Engineered By Newmen, 12mm, Boost, 6-Bolt
  • Front Tyre
    Schwalbe Magic Mary, Performance, 2.4
  • Rear Tyre
    Schwalbe Big Betty, Performance, 2.4
  • Saddle
    ACID Venec Lite
  • Seat Post
    CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
  • Colour
    Dazzle´n´black
  • Weight
    25,2 kg
