Giant Reign E+ 3 MX Pro eMountain Bike 2023 in Amber Glow/Black

Every trail, every steep climb, every thrilling descent.

Giant

Giant Reign E+ 3 MX Pro eMountain Bike 2023 in Amber Glow/Black

£3,849.00 £5,499.00 30% off

Size Guide

Earn

in Customer Rewards when you buy this item today

Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

Earn Rewards

When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

Hassle free returns

In the unlikely event that you are not satisfied with your purchase please feel free to return your items within 90 days of the purchase date for a full exchange or refund. Any item (excluding food, underwear or e-gift vouchers) can be returned to us for any reason within 90 days, provided that the item has not been used or fitted and is returned in its original packaging with valid proof of purchase.

It is recommended that you use a recorded delivery service or return to a store to ensure your items are received by us. We cannot assume responsibility for items that are lost in transit back to us.

Returning an item

Online or in-store purchases can be returned to any of our 12 stores free of charge or can be returned by post or courier at your cost after completing the online returns form below. If you are returning an item due to a fault, we will refund your postage costs.

Bikes & Bulky items

If you wish to return a bike or bulky item to us, please keep the box it arrived in and let us know by contacting our support team via our online webchat, email or by phone (020 45063856) and we will help arrange a collection.

Non Bike - Customer Returns Form

If you wish to return or exchange an item, please fill out the form below following the steps inside. Returns can be processed quicker if all required information is provided.

Terms & Conditions

Items must be returned in their original packaging and unused. Refunds will be issued once the product(s) have been received and inspected.

Click & Collect customers can buy with confidence knowing that they can review the item before deciding whether it is right for you before leaving the store. Should you decide it's not right for you, it can be conveniently exchanged or refunded straight away, or you still have up to 90 days to return it if you are still unsure.

Please note:
1. If the items we have sent you are faulty, damaged or not as we described, we will cover the cost of collection and the delivery of the correct item.

2. If we have delivered the correct bike but upon inspection, you decide the bike is not the one for you, we will charge you £50 for collection (£100 from Northern Ireland). If you do not have the original box in usable condition, we will charge you an additional £15 to provide one.

Refunds will be processed using the same method of payment used for the original purchase. Credit & debit card refunds must be made to the card used for the original purchase.

We are unable to offer a refund without a valid proof of purchase.

Giant Reign E+ 3 MX Pro eMountain Bike 2023 in Amber Glow/Black

Season:2024

Brand:Giant

Code:2113338AMBGlowBLK

Tested and developed by Giant's eBike Enduro pros, this updated trail ripper gives you the power to enjoy the best parts of the ride again and again.

A 29-inch front wheel and 27.5-inch rear wheel work together to offer superior handling and agility on technical terrain. The updated frameset features new geometry with a shorter rear end and longer reach. New control units include RideControl Go, which is integrated into the top tube, and RideControl Ergo 3, attached to the handlebar near the grip. A new flip chip feature lets you adjust frame geometry for riding style and terrain.

Trail technology - Proven Maestro rear suspension (160mm) and a powerful but compact SyncDrive Pro motor technology boost your capabilities on steep climbs and rugged descents.

Total control - RideControl Ergo 3 offers integrated, user-friendly button controls that are easy to use. The Giant E-bike App gives you tuning options and E-bike specific fitness tracking.

Long-lasting power - Climb steep mountains and enjoy fun descents all day long with the downtube-integrated EnergyPak

Key Features & Benefits:

Smooth power delivery:New high-performance SyncDrive Pro motor delivers 85Nm of torque and 400 percent tunable support.
Responsive hardtail handling: Proven Maestro rear suspension (160mm)
Longer range:New integrated RideControl Go and RideControl Ergo 3 units offer clean, simple control buttons, and the EnergyPak Smart battery system increases range by up to 20 percent.

Full Specification:

Frame:ALUXX SL-grade Aluminum, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, 'Boost' 148x12mm, UDHTM derrailleur hanger
Fork:RockShox Domain R 29er, 170mm travel, Motion Control damper, 15x110 Boost, Maxle Stealth
Rear Shock:Fox Float DPS Performance, EVOL Large Volume sleeve, 2-position lever, 205x62.5mm Trunnion mount, custom tuned
Motor:SyncDrive Pro, 85Nm, powered by Yamaha
Controller:RideControl Ergo 3, grip integrated
Display:RideControl GO, frame integrated LED displayANT+ Wireless display compatible
Battery:EnergyPak Smart 625Wh, EnergyPak Plus range extender compatible, EnergyPak 6A smart charger compact
Number of Gears:12
Gear Shifters:Shimano Deore
Chainset:Praxis WaveTM 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S/M:160, L/XL:165)
Chainrings:36T
Rear Cassette:Shimano CS-M6100-12, 10-51T, 12-speed
Chain:KMC e.12 Turbo, EcoProteq, e-bike optimised
Front Derailleur:MRP 1X HD2 custom co-molded chain guide
Rear Derailleur:Shimano Deore 12-speed, Shadow+
Bottom Bracket:Giant Integrated
Pedals:N/A
Rims:Giant AM 29"[F] 27.5"[R], Tubeless ready, 30mm inner width
Front Hub:Shimano MT410 Boost, Center-Lock, [F] 110x15 Thru-axle
Rear Hub:Shimano MT410 Boost, Center-Lock, [R] 148x12mm Micro-Spline Drive Body Thru-axle
Front Tyre:Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra
Rear Tyre:Maxxis High Roller II 27.5x2.5" foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound
Brakes:Shimano BR-M4120, 4-piston, hydraulic disc, 203mm
Handlebars:Giant Contact 35 Trail, 35x800mm
Handlebar Grips:Giant Tactal Pro-E, single lock-on
Stem:Giant Contact SL 35
Saddle:Giant Romero Trail
Seatpost:GiantContact Switch, dropper, 30,9mm (S:125, M: 150, L/XL:170)
Accessories:Giant EnergyPak Smart 6A charger Tubeless kit (liquid, valves, levers, manual, tool).
Weight:

Optional Extras: Lighting- Giant Recon series e-bike lights available and direct connectable, Lock -Torx 25 Battery Lock with built-in Torque limiter

Manufacturers reserve the right to change specifications without notice based on availability at the point of assembly.

Sizing Chart for Giant Reign E+

Frame Size	Rider Height (cm)
S	5'3" – 5'7"
M	5'7" – 6'0"
L	6'0" – 6'4"
XL	6'0" >

Geometry Chart for Giant Reign E+

		S	M	L	XL
		LOW\|HIGH	LOW\|HIGH	LOW\|HIGH	LOW\|HIGH
A	SEAT TUBE LENGTH(mm)	400	425	450	475
B	SEAT TUBE ANGLE	76.7°\|77.5°	76.7°\|77.5°	76.7°\|77.5°	76.7°\|77.5°
C	TOP TUBE LENGTH(mm)	569\|568	595\|594	622\|621	649\|648
D	HEAD TUBE LENGTH(mm)	100	100	110	120
E	HEAD TUBE ANGLE	63.7°\|64.5°	63.7°\|64.5°	63.7°\|64.5°	63.7°\|64.5°
F	FORK RAKE(mm)	44	44	44	44
G	TRAIL(mm)	135.5\|132.1	135\|132	135\|132	135.5\|132.1
H	WHEELBASE(mm)	1209\|1210	1236\|1237	1265\|1266	1295\|1296
I	CHAIN STAY LENGTH(mm)	454\|454	454\|454	454\|454	454\|454
J	BOTTOM BRACKET DROP(mm)	25\|15	25\|15	25\|15	25\|15
K	STACK(mm)	636\|632	635\|632	645\|641	654\|650
L	REACH(mm)	425\|430	450\|455	475\|480	500\|505
M	STAND OVER HEIGHT(mm)	785\|789	772\|776	771\|775	768\|772
N	HANDLEBAR WIDTH(mm)	800	800	800	800
O	STEM LENGTH(mm)	40	40	50	50
P	CRANK LENGTH(mm)	160	160	165	165
Q	WHEEL SIZE	F29" / R27.5"	F29" / R27.5"	F29" / R27.5"	F29" / R27.5"

Warranty Information for Giant

Component	Warranty Period
Bicycle frame (Downhill excluded)	Lifetime
Rigid Forks	10 Years
Downhill frame	3 Years
Giant own brand components, Pedals, grips, bar tape, saddle, Paint & Decals	2 Years
Electronic E-bike components including battery	2 Years (or 600 charge cycles)

For full warranty policy please visit giant-bicycles.com

Technical Information

Motor
SyncDrive Pro, 85Nm, powered by Yamaha
Controller
RideControl Ergo 3, grip integrated
Display
RideControl GO, frame integrated LED displayANT+ Wireless display compatible
Battery
EnergyPak Smart 625WhEnergyPak Plus range extender compatible
Charger
EnergyPak 6A smart charger
Sizes
S, M, L, XL
Colours
Amber Glow
Frame
ALUXX SL-grade Aluminum, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, 'Boost' 148x12mm, UDHTM derrailleur hanger
Fork
RockShox Domain 29er, 170mm travel, Motion Control damper, 15x110 Boost, Maxle Stealth
Shock
Fox Float DPS Performance, EVOL Large Volume sleeve, 2-position lever, 205x62.5mm Trunnion mount, custom tuned
Handlebar
Giant Contact Trail, 35x800mm
Grips
Giant Tactal Pro-E, single lock-on
Stem
Giant Contact SL 35
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:125, M: 150, L/XL:170)
Saddle
Giant Romero Trail
Pedals
Flat pedal
Shifters
Shimano Deore
Front Derailleur
MRP 1X HD2 custom co-molded chain guide
Rear Derailleur
Shimano Deore 12-speed
Brakes
Shimano Deore BR-M4120, 4-piston, hydraulic disc, 203mm
Brake Levers
Shimano Deore BL-M4100, I-spec EV
Cassette
Shimano Deore CS-M6100-12, 10-51T, 12-speed
Chain
KMC e.12 Turbo, EcoProteq, e-bike optimised
Crankset
Praxis WaveTM 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S/M:160, L/XL:165)
Bottom Bracket
-
Rims
Giant AM 29"[F] 27.5"[R], Tubeless ready, 30mm inner width
Hubs
Shimano MT410 Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
Spokes
Sapim E-Lite [r] Race [f]
Tyres
Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra[F]Maxxis High Roller II 27.5x2.5" foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R]
Extras
Tubeless kit (liquid, valves, levers, manual, tool)
Lighting
Optional:- Giant Recon series e-bike lights available and direct connectable
Lock
Torx 25 Battery Lock with built-in Torque limiter
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
