The Trek Procaliber 9.5 Gen 3 is a lightweight carbon XC hardtail with IsoBow tech, 120 mm RockShox fork and Shimano Deore 12-speed — fast, smooth and race-ready.
The Trek Procaliber 9.5 Gen 3 is a lightweight carbon XC hardtail with IsoBow tech, 120 mm RockShox fork and Shimano Deore 12-speed — fast, smooth and race-ready.
Trek

Trek Procaliber 9.5 Gen 3 Hardtail Mountain Bike 2026 in Matte Keswick Green/Mercury

£1,750.00
Earn
in Customer Rewards when you buy this item today
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

Hassle free returns

In the unlikely event that you are not satisfied with your purchase please feel free to return your items within 90 days of the purchase date for a full exchange or refund. Any item (excluding food, underwear or e-gift vouchers) can be returned to us for any reason within 90 days, provided that the item has not been used or fitted and is returned in its original packaging with valid proof of purchase.

It is recommended that you use a recorded delivery service or return to a store to ensure your items are received by us. We cannot assume responsibility for items that are lost in transit back to us.




Terms & Conditions

Items must be returned in their original packaging and unused. Refunds will be issued once the product(s) have been received and inspected.

Click & Collect customers can buy with confidence knowing that they can review the item before deciding whether it is right for you before leaving the store. Should you decide it's not right for you, it can be conveniently exchanged or refunded straight away, or you still have up to 90 days to return it if you are still unsure.

Please note:
1. If the items we have sent you are faulty, damaged or not as we described, we will cover the cost of collection and the delivery of the correct item.

2. If we have delivered the correct bike but upon inspection, you decide the bike is not the one for you, we will charge you £50 for collection (£100 from Northern Ireland). If you do not have the original box in usable condition, we will charge you an additional £15 to provide one.

Refunds will be processed using the same method of payment used for the original purchase. Credit & debit card refunds must be made to the card used for the original purchase.

We are unable to offer a refund without a valid proof of purchase.

Trek Procaliber 9.5 Gen 3 Hardtail Mountain Bike 2026 in Matte Keswick Green/Mercury

Season:2026

Brand:Trek

Code:47223GN-CH

The Procaliber 9.5 Gen 3 is a race-ready carbon hardtail ready to rocket up singletrack climbs. It packs in IsoBow vibration-damping tech to smooth out the chatter and aggressive XC geometry that's confident, capable and nimble.

You're ready to rip through the cross-country course and don't want to lose any efficiency to full-suspension squish. You want the added comfort of IsoBow and components that don't break the bank.

An OCLV Mountain Carbon frame with IsoBow trail-smoothing tech. A RockShox Judy GOLD fork with 120 mm of travel, a Solo Air spring and TurnKey lockout. Shimano's 12-speed Deore drivetrain with hydraulic brakes, a Bontrager Line Dropper post and tubeless 29" wheels.

When you want a carbon XC race bike that doesn't break the bank, reach for the Procaliber 9.5 Gen 3. This lightweight cross-country hardtail delivers trail-smoothing tech and workhorse components for the miles ahead.

Key Features & Benefits:

  • IsoBow:Provides added comfort that won't lose any efficiency as you rip cross-country.
  • OCLV Mountain Carbon Frame:Intensely light, stiff and responsive.
  • Shimano 12-Speed Deore Drivetrain:A wide range of gears, so you can ease the ups in the big ring or stomp to the front in the flats.

Full Specification:

  • Frame:OCLV Mountain Carbon, IsoBow, tapered head tube, internal routing, balanced post-mount brake, Boost148
  • Rear Shock:N/A
  • Fork:RockShox Judy GOLD, Solo Air spring, TurnKey lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel
  • Number of Gears:12
  • Gear Shifters:Shimano Deore M6100, 12-speed
  • Chainset:Shimano MT512, 32T, 55 mm chain line, S/M/ML: 170 mm, L/XL: 175 mm length.
  • Chainrings:32T
  • Rear Cassette:Shimano Deore M6100, 10-51, 12-speed
  • Chain:Shimano Deore M6100, 12-speed
  • Rear Derailleur:Shimano Deore M6100, long cage
  • Bottom Bracket:Shimano MT500, 92 mm, PressFit
  • Pedals: Not supplied:Shop pedals here
  • Rims:Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
  • Front Wheel:Bontrager Kovee
  • Rear Wheel:Bontrager Kovee
  • Front Tyre:Bontrager Sainte-Anne Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40"
  • Rear Tyre:Bontrager Sainte-Anne Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40"
  • Brakes:Shimano MT200 hydraulic disc
  • Handlebars:Size: S - Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width, Size: M, ML, L, XL - Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750mm width
  • Handlebar Grips:Bontrager XR Trail Comp, nylon lock-on
  • Headset:FSA IS-2, 1-1/8" top, 1.5" bottom
  • Stem:Size: S - Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length, Size: M, ML - Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length, Size: L - Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length, Size: XL - Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
  • Saddle:Verse Short, chromoly rails, 145 mm width
  • Seatpost:Size: S - Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length, Size: M, ML, L - Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6 mm, 410 mm length, Size: XL - Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
  • Accessories:N/A
  • Weight:M - 12.13 kg / 26.75 lbs (with TLR sealant, no tubes), This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
Manufacturers reserve the right to change specifications without notice based on availability at the point of assembly.

Size Guide for Trek Procaliber

SizeRider HeightRider HeightInseamInseam
S155 - 165 cm5'1" - 5'5"74 - 78 cm29" - 31"
M165 - 176 cm5'5" - 5'9"79 - 83 cm31" - 33"
M/L173 - 180 cm5'8" - 5'11"81 - 86 cm32" - 34"
L177 - 188 cm5'10" - 6'2"84 - 89 cm33" - 35"
XL188 - 195 cm6'2" - 6'5"89 - 91 cm35" - 36"

Geometry Information for Trek Procaliber


Frame size letterSMMLLXL
Wheel size29"29"29"29"29"
A — Seat tube39.042.044.446.051.0
B — Seat tube angle71.0°71.5°72.0°72.5°73.0°
Effective seat tube angle74.3°74.3°74.3°74.3°74.3°
C — Head tube length999912
D — Head angle67.0°67.0°67.0°67.0°67.0°
E — Effective top tube57.759.861.362.867.7
F — Bottom bracket height6.46.46.46.46.4
G — Bottom bracket drop43.043.043.043.043.0
H — Chainstay length4.34.34.34.34.3
I — Offset111.0113.5115.5117.1122.7
J — Trail74.774.975.876.379.1
K — Wheelbase40.543.044.546.050.0
L — Standover61.461.461.461.464.2

Warranty Information for Trek:

Lifetime warranty on Frame sets (frame and rigid fork), main frame and full suspension swing arms for the lifetime of the original owner, and Bontrager wheels with carbon rims.

2-year warranty on Rear suspension linkage components, including bearings, rocker link and accompanying hardware and components, Bontrager wheels with alloy rims, Paint and transfers.

For full warranty policy please visit trekbikes.com
