Lightweight aluminium e-road bike with TQ-HPR60 motor, SRAM Apex 12-speed, and range extender compatibility for epic climbs and rides
Lightweight aluminium e-road bike with TQ-HPR60 motor, SRAM Apex 12-speed, and range extender compatibility for epic climbs and rides
Trek

Trek Domane+ ALR 5 Electric Road Bike 2026 in Matte Dark Star

£4,000.00
Earn
in Customer Rewards when you buy this item today
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

Hassle free returns

In the unlikely event that you are not satisfied with your purchase please feel free to return your items within 90 days of the purchase date for a full exchange or refund. Any item (excluding food, underwear or e-gift vouchers) can be returned to us for any reason within 90 days, provided that the item has not been used or fitted and is returned in its original packaging with valid proof of purchase.

It is recommended that you use a recorded delivery service or return to a store to ensure your items are received by us. We cannot assume responsibility for items that are lost in transit back to us.




Terms & Conditions

Items must be returned in their original packaging and unused. Refunds will be issued once the product(s) have been received and inspected.

Click & Collect customers can buy with confidence knowing that they can review the item before deciding whether it is right for you before leaving the store. Should you decide it's not right for you, it can be conveniently exchanged or refunded straight away, or you still have up to 90 days to return it if you are still unsure.

Please note:
1. If the items we have sent you are faulty, damaged or not as we described, we will cover the cost of collection and the delivery of the correct item.

2. If we have delivered the correct bike but upon inspection, you decide the bike is not the one for you, we will charge you £50 for collection (£100 from Northern Ireland). If you do not have the original box in usable condition, we will charge you an additional £15 to provide one.

Refunds will be processed using the same method of payment used for the original purchase. Credit & debit card refunds must be made to the card used for the original purchase.

We are unable to offer a refund without a valid proof of purchase.

Trek Domane+ ALR 5 Electric Road Bike 2026 in Matte Dark Star

Season:2026

Brand:Trek

Code:56167BK

The Domane+ ALR 5 is an aluminium electric road bike with a smooth, quiet and natural-feeling boost. Its TQ HPR60 motor gives you plenty of support for long rides and big climbs, and pairs with a SRAM Apex 12-speed drivetrain for clean, consistent shifts.

Key Features and Benefits:

  • Range extender compatible: Increase your range with a 250 Wh plug-and-play Range Extender battery that sits in your bottle cage
  • TQ Motor: Lightweight and quiet
  • SRAM Apex drivetrain:Delivers exceptional shifting, with a wide range of gears suitable for all terrain.

Full Specification:

  • Frame: 300 Series Alpha Aluminium, TQ drive system, hidden mudguard mounts, rack mounts, integrated frame bag mounts, internal cable routing, flat-mount disc, integrated chainkeeper, UDH, 142x12 mm chamfered thru axle
  • Fork: Domane ALR carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, chamfered 12x100 mm thru axle
  • Motor: TQ-HPR60, 60 Nm, 300 watt maximum continuous rated power, 350 watt peak power
  • Battery:TQ 360Wh
  • Controller: TQ LED Display with Bluetooth and ANT+ connectivity
  • Number of Gears:12
  • Gear Shifters:SRAM Apex, 12-speed
  • Chainset:Praxis Alloy XS/S 165mm, M/ML 170mm, L/XL 172.5mm
  • Rear Cassette:SRAM XPLR PG-1231, 11-44, 12-speed
  • Chain:SRAM Apex, 12-speed
  • Front Derailleur:NA
  • Rear Derailleur:SRAM Apex XPLR, 44T max cog
  • Bottom Bracket:NA
  • Rims:Bontrager Paradigm 23, Tubeless Ready, 24-hole, 23 mm width, Presta valve
  • Front Hub: Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle
  • Rear Hub: Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle
  • Front Tyre:Bontrager Kwaremont Pro GR, tubeless ready, folding bead, dual compound, 120 tpi, 700x32 mm
  • Rear Tyre:Bontrager Kwaremont Pro GR, tubeless ready, folding bead, dual compound, 120 tpi, 700x32 mm
  • Brakes:SRAM Paceline, rounded, CentreLock, 160 mm
  • Handlebars:Bontrager Comp Alloy. 80mm Reach 12mm Drop. XS 36 cm control 40cm drop width. S 28/42. M/ML 40/44. L/XL 42/46
  • Tape:Trek EcoTack
  • Stem:Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, XS 70mm, S 80mm, M 90mm, ML/L 100mm, XL 110mm
  • Seatpost:Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
  • Saddle:Verse Short Comp, steel rails, 145 mm width
  • Accessories: 2A, 42V output, 100V–240V AC input charger, Max Tyre size 38c without mudguards, 35c with mudguards
  • Weight:ML - 14.39 kg / 31.73 lbs This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
Manufacturers reserve the right to change specifications without notice based on availability at the point of assembly.

Size Guide for Trek Domane+ ALR Electric Bikes

This chart can give a recommendation on which size may be best for you, however for the best results, please contact us or visit your local Balfe’s store for a personal consultation and test ride.
SizeRider HeightInseam
XS (47cm)143 - 158 cm67 - 74 cm
4'8" - 5'2"26" - 29"
S (50cm)158 - 162 cm74 - 76 cm
5'2" - 5'4"29" - 30"
M (52-54cm)162 - 173 cm76 - 81 cm
5'4" - 5'8"30" - 32"
ML (56cm)173 - 179 cm81 - 84 cm
5'8" - 5'10"32" - 33"
L (58cm)179 - 188 cm84 - 88 cm
5'10" - 6'2"33" - 35"
XL (60-62cm)188 - 213 cm88 - 100 cm
6'2" - 7'0"35" - 39"

Geometry for Trek Domane+ ALR


Frame size letterXSSMMLLXL
Wheel size700c700c700c700c700c700c
A — Seat tube4447.65053.355.359.3
B — Seat tube angle73.5°73.7°73.5°73.3°73.3°73.3°
C — Head tube length10.613.915.918.020.223.6
D — Head angle71.3°71.1°71.5°71.9°72.0°72.1°
E — Effective top tube52.253.254.355.556.457.7
G — Bottom bracket drop8.08.08.07.87.87.5
H — Chainstay length434343434343
I — Offset5.35.35.34.84.84.8
J — Trail6.46.66.36.66.56.4
K — Wheelbase99.7101.2101.8102.0102.9104.3
L — Standover72.175.377.580.582.686.3
M — Frame reach36.837.137.437.73838.4
N — Frame stack52.455.557.559.661.864.6


Warranty Information for Trek:

Lifetime warranty on Frame sets (frame and rigid fork), main frame and full suspension swing arms for the lifetime of the original owner, and Bontrager wheels with carbon rims.

2-year warranty on Rear suspension linkage components, including bearings, rocker link and accompanying hardware and components, Bontrager wheels with alloy rims, Paint and transfers.

For full warranty policy please visit trekbikes.com
